CyberPower PR750ELCDRT1U, Line-Interactive, 750 VA, 500 W, Sine, 150 V, 30 V
The Professional Rackmount LCD Series provides advanced level of power protection to mission-critical servers, telecom equipment, VOIP and internet working hardware. Featuring Pure Sinewave output and Automatic Voltage Regulation (AVR), it can stabilize AC signal or deliver seamless power to connected equipment .The Multifunction LCD Readout indicates critical power/battery conditions. The included PowerPanel Business Edition management software provides comprehensive network power management including unattended-shutdown, event logging, reporting, and notifications. The patented GreenPower UPS technology can reduce energy costs by up to 75% and dissipate 80% less heat than competitive models. An optional SNMP/HTTP Remote Management Capabilities enables remote management of the system through standard web browser.
| Features | |
| UPS topology The two main UPS topologies are Double-Conversion True Online and Standby / Eco. Many quality-based considerations are involved when choosing the the optimal UPS for the job, like how they are coping with voltage disturbances. | Line-Interactive |
| Output power capacity The maximum power that the device can produce. | 750 VA |
| Output power The power that the device can produce. | 500 W |
| Waveform | Sine |
| Input operation voltage (min) The minumum voltage needed by the device during operation. | 150 V |
| Input operation voltage (max) The maximum input voltage supported by the device. | 30 V |
| Input frequency The frequency (Hz) which is required to power the product. | 47/63 Hz |
| Output frequency | 50/60 Hz |
| Automatic Voltage Regulation (AVR) |
 |
| Emergency Power Off (EPO) |
|
| EMI/RFI noise filtering |
|
| Surge protection |
|
| Power protection features Features that protect the device against power problems e.g. overload. | Overload |
| Audible alarm(s) Alarms that make a sound when they are activated (set off). |
|
| Web-based management Using a website/web application to manage something. |
|
| Management protocols | SNMP/HTTP |
| Auto-restart |
|
| Ports & interfaces | |
| AC outlet types The type of outlet for AC electricity. | C13 coupler |
| Power plug A power plug is a 2 or 3 pinned device that is placed into an electrical socket in order to make an electrical connection. | C14 coupler |
| AC outlets quantity The number of sockets in the device where AC electrical power can be connected. | 6 AC outlet(s) |
| USB 2.0 ports quantity Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black. | 1 |
| Serial ports quantity The number of serial ports in a computer or peripheral. A serial port is a serial communication physical interface through which information transfers in or out one bit at a time. The term "serial port" usually identifies hardware more or less compliant to the RS-232 standard, intended to interface with a modem or with a similar communication device. In modern computers and peripherals, serial ports have largely been replaced by USBs and other interfaces. | 1 |
| Emergency Power Off (EPO) connector |
|
| Battery | |
| Battery technology The type of battery in the device, e.g. nickel–cadmium (NiCd). | Sealed Lead Acid (VRLA) |
| Battery capacity The amount of electric charge a battery can deliver at the rated voltage. The more electrode material contained in the cell the greater its capacity. A small cell has less capacity than a larger cell with the same chemistry, although they develop the same open-circuit voltage. Capacity is measured in units such as amp-hour (A·h). | 9 Ah |
| Battery voltage The voltage (V) of the battery. | 6 V |
| Number of batteries supported The number of batteries that can be used with the product. | 4 |
| Typical backup time at full load The amount of time that a backup energy source (e.g. UPS - Uninterruptible Power Source) can power the device for, when the backup energy source is fully loaded (100% of capacity). | 7 min |
| Typical backup time at half load The amount of time that a backup energy source (e.g. UPS - Uninterruptible Power Source) can power the device for, when the backup energy source is half-loaded (50% of capacity). | 23 min |
| Battery recharge time Approximate time required to recharge the battery from completely empty to completely full | 6 h |
| Hot-swap battery |
|
| Automatic battery test |
|
| Design | |
| Form factor The shape or design of the product. | Rackmount |
| Housing material What the casing of the product is made of. | Metal |
| Rack capacity The spase that device fill in rack. | 1U |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| LED indicators |
|
| Display The description of display that can includes display type, resolution, size etc. | LCD |
| RoHS compliance The Restriction of Hazardous Substances (RoHS) Directive aims to restrict certain dangerous substances commonly used in electrical and electronic equipment. Any RoHS compliant product is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). PBB and PBDE are flame retardants used in several plastics. For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials. Any RoHS compliant component must have 100 ppm or less of mercury and the mercury must not have been intentionally added to the component. In the EU, some military and medical equipment are exempt from RoHS compliance. |
|
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 430 mm |
| Depth The distance from the front to the back of something. | 490 mm |
| Height The measurement of the product from head to foot or from base to top. | 44 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 17.6 kg |
| Packaging data | |
| Bracket |
|
| Cables included | USB cable |
| Manual |
|
| Resource CD |
|
| Bundled software Software distributed with another product such as a piece of computer hardware or other electronic device, or a group of software packages which are sold together. A software suite is an example of bundled software, as is software which is pre-installed on a new computer. | PowerPanel Business Edition |
| Other features | |
| Output voltage | 230 V |
| SKU | 345982 |
| MPN | PR750ELCDRT1U |
| Brand | Cyberpower |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.cyberpowersystems.com/ |
