CyberPower BM100, Buttons, Status, System, Metal, CE, FCC Class A, LCD, RJ-45
CyberPower BM100 is part of a battery management system, which consists of Battery Manager and Battery Probes. The system provides a proactive approach to manage and monitor the battery system, eliminating the risk of downtime by ensuring the UPS batteries are optimally charged and ready for use. The system can detect the flawed battery early to reduce the possibility of damage to the entire battery string, thus extending the battery lifespan and delivering a reduced cost of maintenance.
The battery management system can monitor up to several strings of batteries and equalize each battery's voltage, which enhances battery performance. After installing the hardware and configuring an IP address, users can simply monitor the battery voltage, temperature and internal resistance through the user-friendly web interface.
The battery management system can support Environmental Sensor and user upgradeable firmware. The battery management system is fully Ethernet TCP/IP compatible with integrated web server and supports SNMP/MIB communication, data record, alarm notification, and more. The system can also operate under wide temperature range.
The battery management system can monitor up to several strings of batteries and equalize each battery's voltage, which enhances battery performance. After installing the hardware and configuring an IP address, users can simply monitor the battery voltage, temperature and internal resistance through the user-friendly web interface.
The battery management system can support Environmental Sensor and user upgradeable firmware. The battery management system is fully Ethernet TCP/IP compatible with integrated web server and supports SNMP/MIB communication, data record, alarm notification, and more. The system can also operate under wide temperature range.
| Features | |
| Control type The way in which the device is controlled. | Buttons |
| LED indicators | Status, System |
| Housing material What the casing of the product is made of. | Metal |
| RoHS compliance The Restriction of Hazardous Substances (RoHS) Directive aims to restrict certain dangerous substances commonly used in electrical and electronic equipment. Any RoHS compliant product is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). PBB and PBDE are flame retardants used in several plastics. For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials. Any RoHS compliant component must have 100 ppm or less of mercury and the mercury must not have been intentionally added to the component. In the EU, some military and medical equipment are exempt from RoHS compliance. |
 |
| Certification | CE, FCC Class A |
| Quantity The number of products there are. | 1 |
| Display | |
| Built-in display A display which is part of the product, so you do not need to attach another display. |
|
| Display type Type of display (screen) e.g. LCD. | LCD |
| Ports & interfaces | |
| Interface type | RJ-45 |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 2 |
| Network | |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates The different speed levels of the Ethernet LAN connection. | 100,1000 Mbit/s |
| Management features | |
| Supported network protocols Network protocols tested as compatible with this product e.g. FTP,HTML, POP. | IPv4, TCP/IP, UDP, SNMPv1, HTTP, NTP, DNS, Telnet, DHCP, SMTP, FTP, IPv6, SNMPv3, HTTPs, SSH, SSL, TLS |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 210 mm |
| Depth The distance from the front to the back of something. | 100 mm |
| Height The measurement of the product from head to foot or from base to top. | 29 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 573 g |
| Package width The distance from one side of the packaging to the other. | 247 mm |
| Package depth The distance from the front to the back of the packaging. | 149 mm |
| Package height The distance from the top to the bottom of the packaging. | 75 mm |
| Package weight Weight of the packaged product. | 967 g |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | -40 - 60 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 65 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 90% |
| Technical details | |
| DC input voltage | 15-60 V |
| SKU | 461522 |
| MPN | BM100 |
| Brand | Cyberpower |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.cyberpowersystems.com/ |
