Power | |
Total power The total power that is needed by the device, or the total power produced by the device. | 1000 W |
AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
AC input frequency | 47 - 63 Hz |
Combined power (+3.3V) | 150 W |
Combined power (+12V) | 1000 W |
Combined power (+5V) | 150 W |
Combined power (-12V) | 9.6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 25 A |
Max output current (+12V) | 83.3 A |
Max output current (+5V) | 25 A |
Max output current (-12V) | 0.8 A |
Max output current (+5Vsb) | 3 A |
Ports & interfaces | |
Motherboard power connector The way in which the motherboard is connected to the power supply. | 20+4 pin ATX |
Number of SATA power connectors | 11 |
Peripheral (Molex) power connectors (4-pin) White 4-pinned connector used to connect a peripheral to the power supply. | 12 |
EPS power connector (8-pin) |
![]() |
Floppy drive power connector | 1 |
PCI Express connector |
![]() |
Cabling type | Modular |
Performance | |
80 PLUS certification | 80 PLUS Gold |
Purpose What the product is used for. | PC |
Power supply unit (PSU) form factor | ATX |
ATX version ATX (Advanced Technology eXtended) is a motherboard form factor specification developed by Intel in 1995. The specification defines the key mechanical dimensions, mounting point, I/O panel, power and connector interfaces between a computer case, a motherboard and a power supply. There are many versions of ATX including ATX12V 1.x and ATX12V v2.3. | 2.4 |
EPS version | 2.92 |
Bearing technology | Rifle |
Mean time between failures (MTBF) Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism. | 100000 h |
RoHS compliance The Restriction of Hazardous Substances (RoHS) Directive aims to restrict certain dangerous substances commonly used in electrical and electronic equipment. Any RoHS compliant product is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). PBB and PBDE are flame retardants used in several plastics. For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials. Any RoHS compliant component must have 100 ppm or less of mercury and the mercury must not have been intentionally added to the component. In the EU, some military and medical equipment are exempt from RoHS compliance. |
![]() |
Design | |
Product colour The colour e.g. red, blue, green, black, white. | Black |
Cooling type The method used to cool the device or to cool the air around the device. | Active |
Fan diameter The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan. | 13.5 cm |
Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 1 fan(s) |
Fan location | Top |
On/off switch The button which is pressed to switch the device on or off. |
![]() |
Weight & dimensions | |
Width The measurement or extent of something from side to side. | 150 mm |
Depth The distance from the front to the back of something. | 160 mm |
Height The measurement of the product from head to foot or from base to top. | 86 mm |
Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 2 kg |
Other features | |
Warranty card |
![]() |
Manual |
![]() |
Power plug type | Type I |
SKU | 216601 |
MPN | CP-9020094-AU |
Brand | Corsair |
Product Condition | Brand New/Unused |
PSU Form Factor | ATX / PS2 |
Stock Availability | Available for Shipping, In Stock at Castle Hill |
Product Use | Gaming |
Warranty Period | 10 Years Warranty |
Warranty Contact | https://www.corsair.com/ |
