Commbox 92" 5K UHD Horizon Interactive Touch Display
Item No:
792539
MPN:
CBIH92
$14,025.00
Payment options
Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
COMMBOX CBIH92, 2.34 m (92"), 2141.92 x 903.63 mm, 450 cd/m2, 1.07 billion colours, 5120 x 2160 pixels, 5K Ultra HD
The Horizon
The big screen for big ideas
Introducing the next generation of intelligent ultra-wide interactive touchscreens. Expand your view, enhance your experience.
Horizon
33% more screen space than an 86"
Experience the expansive 5K ultra-wide display of the Horizon, featuring a unique 21:9 aspect ratio that offers 33% more screen space. This enhancement
boosts accessibility and productivity, especially in hybrid working environments.
Now powered by Android 13 with a hyper-fast chipset, the Horizon 105 delivers the ultimate touchscreen experience,
tailored for Microsoft Teams Rooms and Zoom Rooms. It's designed to elevate the meeting experience and empower your organisation's leadership.
The big screen for big ideas
Introducing the next generation of intelligent ultra-wide interactive touchscreens. Expand your view, enhance your experience.
Horizon
33% more screen space than an 86"
Experience the expansive 5K ultra-wide display of the Horizon, featuring a unique 21:9 aspect ratio that offers 33% more screen space. This enhancement
boosts accessibility and productivity, especially in hybrid working environments.
Now powered by Android 13 with a hyper-fast chipset, the Horizon 105 delivers the ultimate touchscreen experience,
tailored for Microsoft Teams Rooms and Zoom Rooms. It's designed to elevate the meeting experience and empower your organisation's leadership.
| Display | |
| Display diagonal Size of the display for this product, measured diagonally, usually in inches. | 2.34 m (92") |
| Display brightness Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'. | 450 cd/m² |
| Display number of colours | 1.07 billion colours |
| Display resolution The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image. | 5120 x 2160 pixels |
| Anti-glare screen Always gives an optimal view, even in direct sunlight. |
 |
| HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD). | 5K Ultra HD |
| Panel type | LCD |
| LED backlight A backlight is a form of illumination used in liquid crystal displays (LCDs). One type of backlight is made by LEDs, which can be either white or RGB (red green blue). White LEDs are used most often in notebooks and desktop screens, and in virtually all mobile LCD screens. RGB LEDs for backlighting are found in high-end color proofing displays such as HP DreamColor LP2480zx monitor or selected HP EliteBook notebooks, as well as newer consumer grade displays such as Dell's Studio series laptops which have an optional RGB LED display. |
|
| LED backlighting type Backlighting is the illumination of a screen e.g. LCD (liquid crystal display). There are several types of backlighting with LEDs, e.g. full array, edge lit. | Direct-LED |
| Native aspect ratio The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio. | 21:9 |
| Contrast ratio (typical) The difference in light intensity between the brightest white and the darkest black. | 5000:1 |
| Response time The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.) | 6.5 ms |
| Maximum refresh rate | 60 Hz |
| Touchscreen A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers. |
|
| Touchscreen type There are a variety of touchscreen technologies that have different methods of sensing touch, including resistive and capacitive. | Infrared |
| Number of simultaneous touchpoints | 50 |
| Touch resolution | 32767 x 32768 pixels |
| Touch system response time | 5 ms |
| Viewing angle, horizontal Maximum horizontal angle at which a display can be viewed with acceptable visual performance. | 178° |
| Viewing angle, vertical Maximum vertical angle at which a display can be viewed with acceptable visual performance. | 178° |
| Colour gamut | 90% |
| Working area The area that can be worked on. | 2141.92 x 903.63 mm |
| Screen glass thickness | 3 mm |
| Surface material | Tempered glass |
| Pen & touch differentiation |
|
| Palm rejection |
|
| Accuracy touch | 1 mm |
| Computer system | |
| Operating system installed Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices. | Android 13 |
| Operating system version The version of the operating system used e.g. 4.1, 4.2 for Android. | CommBox OS - Lite |
| Built-in processor Whether or not a processor is built into the device. |
|
| Processor cores The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores). | 4 |
| RAM capacity | 8 GB |
| Audio | |
| Built-in speaker(s) The device contains speaker(s) to produce sound. |
|
| Number of built-in speakers | 2 |
| Speaker power | 40 W |
| Built-in subwoofer The product has built-in subwoofer, which is a loudspeaker component designed to reproduce very low bass frequencies. |
|
| Subwoofer RMS power This is a measure of the continuous power (RMS power) produced by a subwoofer. | 15 W |
| Built-in microphone Microphone that is found inside the product. |
|
| Number of microphone arrays | 8 |
| Network | |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
|
| Top Wi-Fi standard Connection of this device is done via Wi-Fi in a high standard. | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office. | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax) |
| Bluetooth Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example. |
|
| Bluetooth version The type of bluetooth technology in the product e.g. Bluetooth Smart (v4.0). | 5.0 |
| Wake-on-LAN ready |
|
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B Touch ports quantity | 3 |
| USB 2.0 ports quantity Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black. | 1 |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 5 |
| USB Type-C ports quantity | 2 |
| HDMI output ports quantity | 1 |
| USB Power Delivery |
|
| USB Power Delivery up to | 100 W |
| DisplayPorts quantity Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data. | 1 |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 2 |
| OPS slot | 1 |
| S/PDIF out port S/PDIF (Sony/Philips Digital Interconnect Format) is a digital audio interconnect used in consumer audio equipment over relatively short distances. The signal is transmitted over either a coaxial cable with RCA connectors or a fibre optic cable with TOSLINK connectors. |
|
| Microphone connectivity How a microphone connect to a device e.g. wirelessly or via a cable and connector. | 3.5 mm |
| Headphone connectivity How headphones connect to a device e.g. wirelessly or via a cable and connector. | 3.5 mm |
| Audio output The type of audio output that the device produces, and the connector(s). | 1 |
| RS-232 ports The number of sockets (ports) for RS-232. An RS-232 serial port was once a standard feature of a personal computer, used for connections to modems, printers, mice, data storage, uninterruptible power supplies, and other peripheral devices. Now it has been largely replaced by USB and other ports. | 1 |
| Ergonomics | |
| Product colour The colour e.g. red, blue, green, black, white. | Black, Grey |
| VESA mounting |
|
| Panel mounting interface The product can be used wih VESA mounting interfaces. | 800 x 600 mm |
| Wall mountable The product can be mounted on (attached to ) a wall. |
|
| Frame material The material e.g. metal, plastic from which the frame is made. | Aluminium |
| Power | |
| Power consumption (max) The maximum amount of power used by the device. | 800 W |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 330 W |
| Power consumption (standby) The amount of electricity that is consumed when the product is on standby. | 0.5 W |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 240 V |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 2203 mm |
| Depth The distance from the front to the back of something. | 89 mm |
| Height The measurement of the product from head to foot or from base to top. | 1000 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 67.6 kg |
| Packaging data | |
| Package width The distance from one side of the packaging to the other. | 2360 mm |
| Package depth The distance from the front to the back of the packaging. | 1140 mm |
| Package height The distance from the top to the bottom of the packaging. | 225 mm |
| Package weight Weight of the packaged product. | 88.5 kg |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Cables included | HDMI, Power, USB Type-A to USB Type-B, USB Type-C |
| Remote control included Component of an electronics device, most commonly a television set, DVD player and home theater systems originally used for operating the device wirelessly from a short line-of-sight distance. |
|
| Mounting kit |
|
| Batteries included |
|
| Eraser included |
|
| Stylus included |
|
| SKU | 792539 |
| MPN | CBIH92 |
| Brand | Commbox |
| Product Condition | Brand New/Unused |
| Product Use | General |
| Stock Availability | Available for Shipping |
