Cisco AIR-PWRADPT3700IN=, WLAN access point, Outdoor, 100-264 V, 47/63 Hz, 60 W, 48 V
Attaching a Power Adapter
If you want to attach a power adapter (AIR-PWRADPT3700NA=, AIR-PWRADPT3700IN=) to the access point on a pole using the mounting bracket AIR-ACCPMK3700= or AIR-ACCPMK3700-2=, use the procedures in the following sections.
Attaching a Power Adapter Using the Mounting Bracket AIR-ACCPMK3700=
To attach a power adapter (AIR-PWRADPT3700NA=, AIR-PWRADPT3700IN=) to the access point on a pole using the mounting bracket AIR-ACCPMK3700=, use the following procedures:
If you want to attach a power adapter (AIR-PWRADPT3700NA=, AIR-PWRADPT3700IN=) to the access point on a pole using the mounting bracket AIR-ACCPMK3700= or AIR-ACCPMK3700-2=, use the procedures in the following sections.
Attaching a Power Adapter Using the Mounting Bracket AIR-ACCPMK3700=
To attach a power adapter (AIR-PWRADPT3700NA=, AIR-PWRADPT3700IN=) to the access point on a pole using the mounting bracket AIR-ACCPMK3700=, use the following procedures:
| Features | |
| Purpose What the product is used for. | WLAN access point |
| Power supply type The type of power supply which this product uses. | Outdoor |
| Power current type | AC-to-DC |
| Input voltage The voltage (V) which is required to power the product. | 100-264 V |
| Input frequency The frequency (Hz) which is required to power the product. | 47/63 Hz |
| Input current | 1 A |
| Output power The power that the device can produce. | 60 W |
| Output voltage | 48 V |
| Output current | 1.25 A |
| Efficiency | 92% |
| Adjustable output voltage |
 |
| Power protection features Features that protect the device against power problems e.g. overload. | Over voltage, Overload |
| International Protection (IP) code The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes". | IP67 |
| Compatibility The other products, software and hardware this product can be used with. | IW3700 Series |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Grey |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | -30 - 60 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -30 - 85 °C |
| Operating relative humidity (H-H) | 0 - 100% |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| SKU | 563304 |
| MPN | AIR-PWRADPT3700IN= |
| Brand | Cisco |
| Product Condition | Brand New/Unused |
| Adapter Type | Power Adapter |
| Product Use | General |
| Warranty Period | 1 Year Hardware Warranty |
| Warranty Contact | https://www.cisco.com/ |
