Cisco CS-Kit-K9 video Conferencing system Group video Conferencing system 15.1 MP Ethernet LAN
Item No:
457112
MPN:
CS-KIT-K9
$13,471.87
Payment options
Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
Cisco CS-KIT-K9, 15.1 MP, Full HD, 720i,720p,1080i,1080p, 60 fps, 16:9, H.264,H.265
Cisco Spark Room Kit is a powerful collaboration solution that integrates with flat panel displays to bring more intelligence and usability to your small to medium-sized meeting rooms whether registered on the premises or through the cloud.
Cisco Spark Room Kit overview
Cisco Spark Room Kit delivers the unmatched video and audio experience customers have come to expect from Cisco. In addition, new capabilities enable even smarter meetings, smarter presentation capabilities, and smarter room and device integrations further removing the barriers to usage and deployment of video in small to medium-sized rooms.
The Room Kit which includes camera, codec, speakers, and microphones integrated in a single device is ideal for rooms that seat up to seven people. It offers sophisticated camera technologies that bring speaker-tracking capabilities to smaller rooms. The product is rich in functionality and experience but is priced and designed to be easily scalable to all of your small conference rooms and spaces whether registered on the premises or to Cisco Spark through the Cisco Collaboration Cloud.
Cisco Spark Room Kit overview
Cisco Spark Room Kit delivers the unmatched video and audio experience customers have come to expect from Cisco. In addition, new capabilities enable even smarter meetings, smarter presentation capabilities, and smarter room and device integrations further removing the barriers to usage and deployment of video in small to medium-sized rooms.
The Room Kit which includes camera, codec, speakers, and microphones integrated in a single device is ideal for rooms that seat up to seven people. It offers sophisticated camera technologies that bring speaker-tracking capabilities to smaller rooms. The product is rich in functionality and experience but is priced and designed to be easily scalable to all of your small conference rooms and spaces whether registered on the premises or to Cisco Spark through the Cisco Collaboration Cloud.
| Technical details | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Product type The sub-category of the product. | Group video conferencing system |
| Video | |
| HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD). | Full HD |
| Megapixel The number (in millions) of light-sensitive picture elements known as pixels actually used by the camera's image sensor (CCD) to record light, and which are reflected to the final number of recorded pixels stored on the memory card. | 15.1 MP |
| Supported video modes The video modes that can be displayed by the device. | 720i,720p,1080i,1080p |
| Maximum frame rate This is the maximum frame rate, also known as frame frequency and frames per second (FPS). It is the frequency (rate) at which an imaging device produces unique consecutive images called frames. The term applies equally well to film and video cameras, computer graphics, and motion capture systems. Frame rate is most often expressed in frames per second (FPS) and is also expressed in progressive scan monitors as hertz (Hz). | 60 fps |
| Aspect ratio The aspect ratio is the ratio of the width of a shape to its height. For example, 4:3 is common for standard displays and 16:9 is the ratio for Widescreen TV. | 16:9 |
| Video formats supported The type of video formats that can be used by this device. | H.264,H.265 |
| Audio | |
| Frequency range The lowest and the hightest frequencies that can be inputted/produced. | 70 - 20000 Hz |
| Voice codecs | G.711,G.722,G.722.1,G.729,OPUS |
| Noise reduction |
 |
| Automatic gain control |
|
| Built-in speaker(s) The device contains speaker(s) to produce sound. |
|
| RMS rated power RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplifiers and loudspeakers. | 24 W |
| Ports & interfaces | |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 3 |
| USB 2.0 ports quantity Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black. | 1 |
| Headphone outputs Number of sockets /ports where headphones are connected. | 1 |
| Line-in |
|
| Network | |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Ethernet LAN data rates The different speed levels of the Ethernet LAN connection. | 10,100,1000 Mbit/s |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
|
| Wi-Fi standards The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office. | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Supported network protocols Network protocols tested as compatible with this product e.g. FTP,HTML, POP. | H.323/SIP |
| Data link protocols | IPv4/IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ |
| Camera | |
| Effective sensor resolution | 15.1 MP |
| Sensor type A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device. | CMOS |
| Image sensor size The total dimensions of the sensor within the camera, given in inches (''). | 1/1.7" |
| Optical zoom (normal mode) | 3x |
| Focus adjustment | Auto |
| Horizontal field of view | 83° |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Power | |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| DC input voltage | 12 V |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 20 W |
| Power consumption (max) The maximum amount of power used by the device. | 70 W |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 700 mm |
| Depth The distance from the front to the back of something. | 88 mm |
| Height The measurement of the product from head to foot or from base to top. | 106 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 3.2 kg |
| Packaging content | |
| Speaker included The product bundle comes with a speaker. |
|
| Camera included This product includes a camera. |
|
| Microphone included |
|
| SKU | 457112 |
| MPN | CS-KIT-K9 |
| Brand | Cisco |
| Product Condition | Brand New/Unused |
| Product Use | General |
| Stock Availability | Available for Shipping |
