Cisco AIR-ANT2524V4C-R=, 4 dBi, 2.4 - 2.483 / 5.15 - 5.85 GHz, 2 dBi, 4 dBi, Omni-directional antenna, RP-TNC
Ceiling mount omnidirectional antenna - Designed for use indoor, this antenna comes with ceiling mount hardware. It has 4 plenum rated pigtail cables, 3 foot each, with four RP-TNC connectors.
| Performance | |
| Frequency band A small section of the spectrum of radio communication frequencies, in which channels are usually used or set aside for the same purpose e.g.for a channel on FM radio; for mobile networks to communicate with mobile phones. | 2.4 - 2.483 / 5.15 - 5.85 GHz |
| Antenna gain (2.4 GHz) | 2 dBi |
| Antenna gain (5 GHz) | 4 dBi |
| Antenna gain level (max) Antenna gain is the measurement of an antenna's ability to amplify the incoming microwave signals in a particular direction, compared with the sensitivity of an isotropic antenna in any direction, or a dipole antenna in the equatorial direction. | 4 dBi |
| Features | |
| Antenna type Type of antenna, also known an aerial, e.g. external, internal. | Omni-directional antenna |
| Antenna connector type The way in which the antenna is connected to the device e.g. coaxial. | RP-TNC |
| Voltage Standing Wave Ratio (VSWR) | 2:1 |
| Cable length How long the cable is. | 0.91 m |
| Mounting What size the mounting head of the product is, to couple it with a camera. | Ceiling |
| Purpose What the product is used for. | Indoor |
| Product colour The colour e.g. red, blue, green, black, white. | White |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 184 mm |
| Depth The distance from the front to the back of something. | 184 mm |
| Height The measurement of the product from head to foot or from base to top. | 25 mm |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| SKU | 605241 |
| MPN | AIR-ANT2524V4C-R= |
| Brand | Cisco |
| Product Condition | Brand New/Unused |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.cisco.com/ |
