Cisco SFP-1G-LH=, Fiber optic, 1000 Mbit/s, SFP, 9/125 m, LH, LX, 50000 m
1000BASE-X modules for 10G ports
1000BASE-SX SFP for multimode fiber only
The SFP-1G-SX module operates in 10G, 10/25G dual rate and 10/25/50G tri-rate ports of Cisco switches and routers, but provides 1G connectivity. The SFP-1G-SX interoperates with 1000BASE-SX modules.
The SFP-1G-SX module will only operate in 10G capable ports and will not operate in 1G only ports.
1000BASE-LX/LH SFP for singlemode fiber and multimode fiber
THE SFP-1G-LH module operates in 10G, 10/25G dual rate and 10/25/50G tri-rate ports of Cisco switches and routers, but provides 1G connectivity. The SFP-1G-LH interoperates with 1000BASE-LX/LH modules.
The SFP-1G-LH module will only operate in 10G capable ports and will not operate in 1G only ports.
1000BASE-SX SFP for multimode fiber only
The SFP-1G-SX module operates in 10G, 10/25G dual rate and 10/25/50G tri-rate ports of Cisco switches and routers, but provides 1G connectivity. The SFP-1G-SX interoperates with 1000BASE-SX modules.
The SFP-1G-SX module will only operate in 10G capable ports and will not operate in 1G only ports.
1000BASE-LX/LH SFP for singlemode fiber and multimode fiber
THE SFP-1G-LH module operates in 10G, 10/25G dual rate and 10/25/50G tri-rate ports of Cisco switches and routers, but provides 1G connectivity. The SFP-1G-LH interoperates with 1000BASE-LX/LH modules.
The SFP-1G-LH module will only operate in 10G capable ports and will not operate in 1G only ports.
| Performance | |
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate The maximum speed with which data can be transmitted from one device to another. | 1000 Mbit/s |
| Interface type | SFP |
| Single-mode fiber (SMF) supported |
 |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| SFP transceiver standard | LH, LX |
| Maximum transfer distance The greatest distance over which the data/signal can be transferred. | 50000 m |
| Wavelength The distance over which a wave repeats itself. The wavelength determines the characteristics of the wave e.g. red light has a different wavelength to blue light. | 1355 nm |
| Ethernet interface type | 100 Gigabit Ethernet |
| Fiber ethernet cabling technology | 100GBASE |
| Auto MDI/MDI-X A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link. |
|
| Features | |
| Hot-swap |
|
| Certificates | |
| Compliance certificates Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies. | RoHS, WEEE |
| Sustainability | |
| Sustainability compliance |
|
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 70 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 10 - 85% |
| SKU | 838910 |
| MPN | SFP-1G-LH= |
| Brand | Cisco |
| Product Condition | Brand New/Unused |
| Product Use | General |
