Cambium 8-Port Gigabit FC Managed PoE Switch

Management features
Switch type What switch device has, managed or unmanaged.	Managed
Switch layer A network switch is a computer networking device that links networking segments. A switch has different layers, such as layer 2 (a network bridge, operating at the data link layer, interconnecting a small number of devices) and layer 4 (can act as a firewall, amongst other things).	L2/L3
Quality of Service (QoS) support
Web-based management Using a website/web application to manage something.
Cloud-managed
Traffic classification
Traffic shaping
ARP inspection
System event log

Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity The number of basic switching RJ-45 Ethernet ports (sockets).	8
Basic switching RJ-45 Ethernet ports type The type/category of basic switching RJ-45 Ethernet ports (sockets).	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	8
SFP+ module slots quantity	4
Fiber ports quantity The number of sockets (ports) for fibers (cables).	4
Fiber optic connector This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced.	SFP+
Console port	RS-232
Power connector	DC-in jack

Network
10G support The product can use Oracle 10G, which is a database management system introduced in 2003.
Port mirroring
Policy-based routing
Flow control support
Link aggregation
Broadcast storm control
Rate limiting
Auto MDI/MDI-X A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.
Spanning tree protocol
Address Resolution Protocol (ARP) entries (max)	512
Number of VLANs	4000

Data transmission
Switching capacity The data transfer capacity of the switch per second.	1000 Gbit/s
Throughput	96 Gbit/s
Forwarding rate	120 Mpps
MAC address table The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.	16000 entries
Static route
Number of static routes	64
Jumbo frames support
Jumbo frames	9000

Security
DHCP features	DHCP relay, DHCP client, DHCP snooping
Access Control List (ACL)
Access Control List (ACL) egress	128
Access Control List (ACL) ingress	128
IGMP snooping
IGMP entries	256
IGMP proxy
MAC address filtering Security access control method whereby the 48-bit address assigned to each network card is used to determine access to the network. MAC addresses are uniquely assigned to each card, so using MAC filtering on a network permits and denies network access to specific devices through the use of blacklists and whitelists.
SSH/SSL support
BPDU filtering/protection
IP-MAC-Port binding
Authentication	MAC-based authentication
Password protection The computer, smartphone etc. can only be used when the correct password is entered, therefore making it more secure.
DoS attack prevention
Authentication type Authentification means proving identity to gain access to sometheng. There are various types of authentification exist e.g. access card, password, biometric data.	AAA, RADIUS, IEEE 802.1x, TACACS+
MAC address entries	Static MAC address entries

Multicast features
Multicast support

Protocols
Management protocols	SSH / SSH v2, SNMP v1/v2/v3

Design
Rack mounting The type of mounting that can position devices in a shelving system (rack).
Stackable Devices can be placed on top of each other.
Product colour The colour e.g. red, blue, green, black, white.	Black
Housing material What the casing of the product is made of.	Metal
Reset button
LED indicators
Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation).	1 fan(s)

Performance
Built-in processor Whether or not a processor is built into the device.
Processor frequency The clock rate is the fundamental rate in cycles per second (measured in hertz) at which a computer performs its most basic operations such as adding two numbers. There are more factors, like internal memory size, that influence a computer's actual response time.	800 MHz
Internal memory The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.	512 MB
Flash memory	128 MB

Power
Power source What is providing power for the product e.g. mains electricity.	DC
Power supply included There is a power supply with this product.
DC input voltage	24 - 56 V
Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.	200 W

Power over Ethernet (PoE)
Power over Ethernet (PoE) The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
Power over Ethernet (PoE) type supported	Passive PoE
Power over Ethernet plus (PoE+) ports quantity	8
Power over Ethernet (PoE) voltage One of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.	24 V
Power over Ethernet (PoE) power per port	90 W
Total Power over Ethernet (PoE) budget	170 W

Operational conditions
Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated.	-30 - 60 °C
Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored.	-40 - 70 °C
Operating relative humidity (H-H)	20 - 90%
Storage relative humidity (H-H)	20 - 90%

Weight & dimensions
Width The measurement or extent of something from side to side.	230 mm
Depth The distance from the front to the back of something.	280 mm
Height The measurement of the product from head to foot or from base to top.	44 mm
Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.	2.1 kg

Packaging data
Package width The distance from one side of the packaging to the other.	330 mm
Package depth The distance from the front to the back of the packaging.	351 mm
Package height The distance from the top to the bottom of the packaging.	101 mm
Package weight Weight of the packaged product.	2.65 kg
