High-Volume Daily Duty Cycle
The Scanner can be used to scan up to 20000 pages per Day through the 150-page automatic Document Feeder. the data indicates that this Scanner is designed to scan Document in any application requiring frequent Document and hard Card scanning.
Dual-lamp Design to Handle Wrinkled Documents
Designed to handle even extreme applications the AD6090 Scanner is built-in with two long-lasting lamps. These mercury-free lamps give you maximum illumination to help eliminate shadows from wrinkled Documents.
Paper Protection Mechanism
The innovative hardware design to implement various jam Sensors on the Paper path greatly improves the sensitivity to detect Paper jams which reduces the risk Of damaging the Document by stopping your scan job.
Plus the Multi-feed detection Technology helps detecting overlapping Documents that go through the auto Document Feeder by either detecting Extra Paper length or Paper thickness through triple Ultrasonic Sensors.
Plastic Card or ID Card uses the Straight Paper path
To Provide Scanner users with the most versatile scanning environments the user has the choice to utilize a U-Turn or Straight Paper Path. By opening the rear cover users can use the Straight path to transport Paper direct to the rear Of the unit. to utilize the Straight Paper path ensures high reliability with plastic Card ID Card thick long Paper or more fragile Documents.
Paper Protection Technology
The advanced Paper Protection Technology Protects valuable Paper from being wrinkled or torn by halting the scan Process once a skewed page is detected.
A Large LCD Display
The AD6090 is Easy to use through the clear 1.8” LCD display. By selecting your destination and pressing the “Scan” Button the scan can be done and the scanned Image can be sent to your specified destination application such as e-mail Printer or your favourable Image-editing software application. Up to nine frequently used scan settings and destinations can be preset for different scanning needs.
Scan to Cloud with Button Manager V2
The AD6090 come with TWAIN and ISIS drivers and are bundled with a suite Of powerful software applications that include Avision Button Manager V2 AVScan x and ScanSoft Paper Port 14SE. with Button Manager V2 you can complete a scan and send the Image directly to cloud Servers such as Google Drive Dropbox Evernote Facebook or Microsoft SharePoint with a press Of a Button. You can also save the Image to searchable PDF JPEG BMP or GIF file Format and scan to e-mail or Image editing application. In addition the bundled software applications also include AVScan x and ScanSoft Paper Port which are highly effective Document management software to streamline your task more efficiently.
Features
- Fast 90 ppm / 180 ipm scanning in color grayscale and monochrome 300 dpi
- Support form Document up to 297 x 432 mm A3
- Robust 150-page 80 g/m² automatic Document Feeder
- Daily Duty cycle Of up to 20000 Sheets
- Ultrasonic Sensor to enable or disable detection in different areas of Document
- Curved or Straight Paper Path
- Auto crop and deskew a Document with the advanced Image Processing unit to enhance the scanning speed
- Latest USB 3.1 Gen1 connectivity for faster transmission speed
- Reverse Roller Technology delivers outstanding Feeding reliability
- Hard and embossed Card scanning up to 1.25 mm in thickness in landscape feeding
- Press and scan to cloud Servers via the bundled software Button Manager
- Earth-friendly LED Technology
- Long page scanning up to 6000 mm 236”
- Auto power of
| Scanning | |
| Maximum scan size | 308 x 432 mm |
| Optical scanning resolution How many pixels a scanner can see. Most commonly, this is measured in dots per inch (dpi).For example, a typical flatbed scanner will use a scanning head with 300 sensors per inch, so it can sample 300 dots per inch (dpi) in one direction. To scan in the other direction, it will move the scanning head along the page, stopping 300 times per inch, so it can scan 300 dpi in the other direction as well. This scanner would have an optical resolution of 300 x 300 dpi. Some manufacturers stop the scanning head more frequently as it moves down the page, so their machines have resolutions of 300 x 600 dpi or 300x1200 dpi. | 600 x 600 DPI |
| Colour scanning Indicates whether this product scans in colour. |
 |
| Duplex scanning Feature of computer scanners and multifunction printers (MFPs) that allows the automatic scanning of a sheet of paper on both sides. |
|
| Input colour depth Colour depth of the input into the product. The colour depth is either the number of bits used to indicate the color of a single pixel, in a bitmapped image or video frame buffer, or the number of bits used for each color component of a single pixel. High-end laptops have 24-bit colour depth. | 48 bit |
| Output colour depth | 24 bit |
| Input greyscale depth | 16 bit |
| Output greyscale depth | 8 bit |
| ADF scan speed (b/w, A4) | 90 ppm |
| ADF scan speed (colour, A4) | 90 ppm |
| Duplex ADF scan speed (b/w, A4) | 180 ipm |
| Duplex ADF scan speed (colour, A4) | 180 ipm |
| Design | |
| Scanner type Indicates the type of scanner this product is. | ADF scanner |
| Product colour The colour e.g. red, blue, green, black, white. | White |
| Display The description of display that can includes display type, resolution, size etc. | LCD |
| Display diagonal Size of the display for this product, measured diagonally, usually in inches. | 4.57 cm (1.8") |
| Control type The way in which the device is controlled. | Buttons |
| Built-in display A display which is part of the product, so you do not need to attach another display. |
|
| Foldable The product can be folded and so can be stored/transported more easily. |
|
| Performance | |
| Sensor type A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device. | CIS |
| Light source | LED |
| Scan file formats | BMP, DOC, DOCS, GIF, HTML, JPEG, OCR, PDF, PNG, PPT, PPTX, RTF, TIFF, TXT, XLS, XLSX, XPS |
| Daily duty cycle (max) The maximum percentage of time a machine or piece of equipment can be in operation for in one day in relation to the time it must remain out of operation. For instance, a max daily duty cycle of 30 percent means it will operate for a maximum 30 percent of the day and then not be used for the other 70 percent of the day. | 20000 pages |
| Scan to | Cloud, E-mail, Print, Software |
| Button functions | down, Off, On, Scan, Up |
| Scan drivers | ISIS,TWAIN |
| Scanner error detection |
|
| Ultrasonic double sheet detection |
|
| Ultrasonic sensor |
|
| Scanning noise level | 58 dB |
| Internal memory The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware. | 1024 MB |
| Input capacity | |
| Auto document feeder (ADF) input capacity Number of sheets this product can hold in its ADF tray; expressed in sheets | 150 sheets |
| Paper handling | |
| Multi feed detection Detector stopping the scan process as soon as 2 pages are scanned together. |
|
| Long-paper mode |
|
| Maximum ISO A-series paper size The maximum paper size the device can handle, defined by ISO A-series. | A3 |
| Card thickness (max) | 1.25 mm |
| Paper tray media weight | 27 - 105 g/m² |
| Auto Document Feeder (ADF) media weight | 27 - 413 g/m² |
| Maximum scan length | 6 m |
| Maximum scan area (ADF) | 308 x 432 mm |
| Minimum scan area (ADF) | 50 x 65 mm |
| Ports & interfaces | |
| USB port The device features a socket into which a USB cable can be plugged. |
|
| USB version Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one. | 3.2 Gen 1 (3.1 Gen 1) |
| Power | |
| Power supply type The type of power supply which this product uses. | AC |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 48 W |
| Power consumption (standby) The amount of electricity that is consumed when the product is on standby. | 14 W |
| Power consumption (off) | 0.2 W |
| AC input frequency | 50/60 Hz |
| Sleep mode |
|
| Input voltage The voltage (V) which is required to power the product. | 100 - 240 V |
| Power consumption (sleep) | 3.1 W |
| Output voltage | 24 V |
| Output current | 6.25 A |
| System requirements | |
| Windows operating systems supported Windows vesions wich can be used with the device. | Windows 10,Windows 7,Windows 8,Windows 8.1 |
| Operational conditions | |
| Operating temperature (T-T) | 50 - 95 °F |
| Operating relative humidity (H-H) | 10 - 85% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 460 mm |
| Depth The distance from the front to the back of something. | 680 mm |
| Height The measurement of the product from head to foot or from base to top. | 198 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 12 kg |
| Folded width | 46 cm |
| Folded depth | 31 cm |
| Folded height | 19.8 cm |
| Packaging content | |
| Software CD |
|
| Cables included | AC, USB |
| Quick start guide Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly. |
|
| Bundled software Software distributed with another product such as a piece of computer hardware or other electronic device, or a group of software packages which are sold together. A software suite is an example of bundled software, as is software which is pre-installed on a new computer. | TWAIN Driver, ISIS Driver, Button Manager, PaperPort, AVScan, WIA Driver |
| Other features | |
| Output resolutions | 75, 100, 150, 200, 300, 400, 600, 1200 |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| SKU | 613529 |
| MPN | AD6090 |
| Brand | Avision |
| Product Condition | Brand New/Unused |
| Printer Type | None |
| Print Scan Features | Scan |
| Scanner Type | Flatbed |
| Wired/Wireless | Wired |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.avision.com/ |
