AudioCodes MediaPack 124, BootP, DHCP, TFTP, HTTP, DHCP, EMS, SNMP V3, HTTPS, SRTP, SSL/TLS, 10/100Base-T(X), 1.8 kg, 445 x 269 x 44 mm, 50/60 Hz
AudioCodes MediaPack 1xx series of Analog VoIP Gateways are cost-effective, stand-alone VoIP gateways that provide superior voice technology for connecting legacy telephones, fax machines and PBX systems with IP telephony networks and IP-based PBX systems. The MediaPack 1xx series gateways support a wide variety of service provider and enterprise applications:
- Service providers can use MediaPack gateways to connect Multi-Tenant Units (MTUs), IP Centrex subscribers, payphones, and rural users over wireless and satellite links
- Enterprises can use MediaPack gateways to connect their legacy PBX systems over an IP infrastructure. In addition, in IP Centrex and central IP-PBX applications, MediaPack enhances remote location availability and provides Stand Alone Survivability (SAS) when there is no IP connection between branch locations and a central SIP server, SIP proxy or central IP-PBX
The MediaPack 1xx gateways are fully interoperable with leading softswitches, SIP servers and H.323 systems.
Features
- Support for 2 to 24 analog ports
- T.38 fax compliant
- Rich subscriber feature set: 3-way conference with local mixing, call pickup, hunt groups, call forwarding, call hold and call transfer
- Echo cancellation, jitter buffer, voice activity detection (VAD) and comfort noise generation (CNG)
- Complies with MGCP, H.323v4 and SIP control protocols
Benefits
- Leverage investment in existing analog telephone, modem, and fax systems easing VoIP migration
- Lifeline for fallback to PSTN for E911 (Emergency number PSTN breakthrough) or upon network/power failure (FXO and/or FXS configurations)
- Standalone Survivability (SAS) keeps your business running in the event of a network failure
- Service providers can use MediaPack gateways to connect Multi-Tenant Units (MTUs), IP Centrex subscribers, payphones, and rural users over wireless and satellite links
- Enterprises can use MediaPack gateways to connect their legacy PBX systems over an IP infrastructure. In addition, in IP Centrex and central IP-PBX applications, MediaPack enhances remote location availability and provides Stand Alone Survivability (SAS) when there is no IP connection between branch locations and a central SIP server, SIP proxy or central IP-PBX
The MediaPack 1xx gateways are fully interoperable with leading softswitches, SIP servers and H.323 systems.
Features
- Support for 2 to 24 analog ports
- T.38 fax compliant
- Rich subscriber feature set: 3-way conference with local mixing, call pickup, hunt groups, call forwarding, call hold and call transfer
- Echo cancellation, jitter buffer, voice activity detection (VAD) and comfort noise generation (CNG)
- Complies with MGCP, H.323v4 and SIP control protocols
Benefits
- Leverage investment in existing analog telephone, modem, and fax systems easing VoIP migration
- Lifeline for fallback to PSTN for E911 (Emergency number PSTN breakthrough) or upon network/power failure (FXO and/or FXS configurations)
- Standalone Survivability (SAS) keeps your business running in the event of a network failure
| Design | |
| LED indicators |
 |
| Safety List of regulatory safety standards for all countries in which this product has been certified. | EN60950-1 |
| Certification | EN55022 , CFR, EN55024, EN61000-3-3, EN61000-3-2, VCCI Class X1 |
| Features | |
| Interface Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2. | 16 x FXS |
| Voice codecs | G.711, G.722, G.723.1, G.726, G.729A, G.729B |
| Performance | |
| Control display unit |
|
| Protocols | |
| Management protocols | BootP, DHCP, TFTP, HTTP, DHCP, EMS, SNMP V3 |
| Network | |
| Cabling technology Type of cable technology performance. | 10/100Base-T(X) |
| Security | |
| Security algorithms Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product. | HTTPS, SRTP, SSL/TLS |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 1 |
| Foreign eXchange Station (FXS) ports quantity | 16 |
| Power | |
| Input voltage The voltage (V) which is required to power the product. | 100 - 240 V |
| Input frequency The frequency (Hz) which is required to power the product. | 50/60 Hz |
| Weight & dimensions | |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 1.8 kg |
| Dimensions (WxDxH) Dimensions of the product (Width x Depth x Height). | 445 x 269 x 44 mm |
| Packaging content | |
| AC adapter included |
|
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 5 - 40 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -20 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| SKU | 652246 |
| MPN | MP124/16S/AC/SIP |
| Brand | AudioCodes |
| Product Condition | Brand New/Unused |
| Product Use | General |
| Warranty Contact | https://www.audiocodes.com/ |
| Stock Availability | Available for Shipping |
