Aten 1L/Remote 1P VGA KVM over IP Switch With Power Distribution Unit
Item No:
700139
MPN:
KN1000-AX-U
$9,999.00
Payment options
Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
ATEN 1 Local/Remote Share Access Single Port VGA KVM over IP Switch with Single Outlet Switched PDU (1600 x 1200), 1600 x 1200 pixels, Ethernet LAN, WUXGA, 6.77 W, Black
The KN1000 is a control unit that provides remote BIOS level access to servers or "over IP" capability to KVM switches that do not have built in over IP functionality. It allows operators to monitor and access their computers from remote locations using a standard Internet browser or Windows/Java based application programs, for BIOS level troubleshooting without the need for constant on site IT maintenance. In addition, the KN1000 offers out of band access " including external modem support.
To help you manage and control multiple widely distributed servers efficiently from a remote console, a built in single port Power Switch allows remote power management of a server/installation connected locally to the KN1000, including turning servers On, Off and Rebooting. In addition, you can also add a PON (Power Over the NET ) power management unit to manage the power status of even more devices. The KN1000 also provides serial console management over the internet which can remotely control serial console devices such as a network switch.
KN1000 s Virtual Media function allows you to perform diagnostic testing, file transfer, and OS and application patches from a remote console. There is no need to physically load a CD directly to the server to perform data related tasks. Conveniently and efficiently troubleshoot and resolve the problems at BIOS level from anywhere.
Both a Windows GUI Client and a Java Applet are also available in browser based and Windows application versions. They are provided for IP connection and login from anywhere on the net. Inclusion of a Java based client ensures that the KN1000 is platform independent, and is able to work with practically all operating systems.
With these advanced features, the KN1000 is the fastest, most reliable, most cost effective way to remotely access and manage widely distributed multiple computer installations, such as kiosks and automated banking.
To help you manage and control multiple widely distributed servers efficiently from a remote console, a built in single port Power Switch allows remote power management of a server/installation connected locally to the KN1000, including turning servers On, Off and Rebooting. In addition, you can also add a PON (Power Over the NET ) power management unit to manage the power status of even more devices. The KN1000 also provides serial console management over the internet which can remotely control serial console devices such as a network switch.
KN1000 s Virtual Media function allows you to perform diagnostic testing, file transfer, and OS and application patches from a remote console. There is no need to physically load a CD directly to the server to perform data related tasks. Conveniently and efficiently troubleshoot and resolve the problems at BIOS level from anywhere.
Both a Windows GUI Client and a Java Applet are also available in browser based and Windows application versions. They are provided for IP connection and login from anywhere on the net. Inclusion of a Java based client ensures that the KN1000 is platform independent, and is able to work with practically all operating systems.
With these advanced features, the KN1000 is the fastest, most reliable, most cost effective way to remotely access and manage widely distributed multiple computer installations, such as kiosks and automated banking.
| Ports & interfaces | |
| Number of computers controlled The amount of computers controlled by this device. | 1 |
| Video port type The type of socket in the device for connecting a video e.g. SCART. | VGA |
| Console ports | VGA (D-Sub) |
| USB connector type The type of USB connector/port that this product has. | Mini-USB B |
| Serial port type | DE-9 (DB-9) |
| Serial ports quantity The number of serial ports in a computer or peripheral. A serial port is a serial communication physical interface through which information transfers in or out one bit at a time. The term "serial port" usually identifies hardware more or less compliant to the RS-232 standard, intended to interface with a modem or with a similar communication device. In modern computers and peripherals, serial ports have largely been replaced by USBs and other interfaces. | 2 |
| DC-in jack The socket/plug where the DC electricity supply connects to the device. |
 |
| Network | |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 1 |
| Performance | |
| HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD). | WUXGA |
| Maximum resolution The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. | 1600 x 1200 pixels |
| Video bandwidth | 60 Hz |
| DDC2B support |
|
| Number of users The number of people that use or can use this product. | 64 user(s) |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Housing material What the casing of the product is made of. | Metal |
| LED indicators |
|
| Push button |
|
| Display | |
| Built-in display A display which is part of the product, so you do not need to attach another display. |
 |
| Power | |
| Power source What is providing power for the product e.g. mains electricity. | AC |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 10 A |
| Output voltage | 100 - 240 V |
| Output current | 9 A |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 6.77 W |
| System requirements | |
| Windows operating systems supported Windows vesions wich can be used with the device. |
|
| Linux operating systems supported 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3) |
|
| Mac operating systems supported Mac operating systems e.g. OS X can be used with the device. |
|
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 81.5 mm |
| Depth The distance from the front to the back of something. | 310 mm |
| Height The measurement of the product from head to foot or from base to top. | 42 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 860 g |
| Packaging content | |
| Cables included | AC, KVM, Mini-USB |
| Manual |
|
| AC adapter included |
|
| Rack mount kit |
|
| SKU | 700139 |
| MPN | KN1000-AX-U |
| Brand | ATEN |
| Product Condition | Brand New/Unused |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.aten.com/ |
