Designed for a two-monitor display; Flat screen monitors: maximum load up to 8kg per monitor; Curved screen monitors: maximum load up to 5.5kg per monitor; Ergonomic; Independent landscape or portrait viewing; Screen sharing capability
| Mounting | |
| Maximum weight capacity The maximum weight that the product is designed to hold/store. | 8 kg |
| Maximum weight capacity (per display) | 8 kg |
| Maximum weight capacity (per curved/ultra-wide display) | 5.5 kg |
| Maximum screen size The maximum screen size which can be used with this product. | 76.2 cm (30") |
| Mounting What size the mounting head of the product is, to couple it with a camera. | Clamp/Bolt-through |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Panel mounting interface The product can be used wih VESA mounting interfaces. | 75 x 75,100 x 100 mm |
| Number of displays supported The number of displays that can be used with this product. | 2 |
| Extension arm (max) | 47.6 cm |
| Desk thickness (max) | 7.6 cm |
| Mounting type Type of mounting e.g. wall mounting. | Desk |
| Ergonomics | |
| Height adjustment The part of the device that can be adjusted to change the height. |
 |
| Tilt angle range | -70 - 70° |
| Angle of rotation | 240° |
| Pan range | 180 - 180° |
| Number of arms | 2 |
| Tilt adjustment The tilt, which means the angle at which the device is pointing (up or down), can be changed. |
|
| Design | |
| Housing material What the casing of the product is made of. | Aluminium, Plastic |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Orientation | Landscape/Portrait |
| Technical details | |
| Product type The sub-category of the product. | Flat panel mount arm |
| Weight & dimensions | |
| Package width The distance from one side of the packaging to the other. | 235 mm |
| Package depth The distance from the front to the back of the packaging. | 560 mm |
| Package height The distance from the top to the bottom of the packaging. | 115 mm |
| Package weight Weight of the packaged product. | 3.8 kg |
| Packaging content | |
| Screws included |
|
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Master (outer) case width | 485 mm |
| Master (outer) case length | 575 mm |
| Master (outer) case height | 250 mm |
| Master (outer) case gross weight | 16.2 kg |
| Products per master (outer) case | 4 pc(s) |
| SKU | 701603 |
| MPN | AF-AT-D-BC |
| Brand | Atdec |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 10 Years Warranty |
| Warranty Contact | https://www.atdec.com.au/ |
