Asus P11C-I C242 LGA 1151 Mini-ITX Server Motherboard

Processor
Processor manufacturer The manufacturer that produced the processor.	Intel
Processor socket Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering.	LGA 1151 (Socket H4)
Compatible processor series A processor which is compatible with this device, belongs to a 'series' which is part of 'family' e.g Celeron D, Celeron G, Celeron M, or, in some cases, is the same as 'family'.	Intel® Celeron®, Intel® Core™ i3, Intel® Pentium®, Intel® Xeon®
Maximum number of SMP processors	1

Memory
Supported memory types Types of memory which can be used with the product.	DDR4-SDRAM
Number of memory slots	2
Memory slots type A memory slot, also known as a memory socket or RAM slot, is what allows computer memory (RAM) to be inserted into the computer. Depending on the motherboard, there will usually be 2 to 4 memory slots (sometimes more on high-end motherboards). The most common types of RAM are SDRAM and DDR for desktop computers and SODIMM for laptop computers, each having various types and speeds.	DIMM
Memory channels	Dual-channel
ECC ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
Non-ECC
Supported memory clock speeds Memory clock speed is the time it takes for a computer to complete basic operations. It refers to the computer's processing speed and is measured in hertz. It is however not such a reliable measure of a computer's speed as it doesn't take into account other factors like RAM and cache size.	2400,2666 MHz
Supported memory module capacities	4GB,8GB,16GB
Maximum internal memory The maximum internal memory which is available in the product.	32 GB

Storage controllers
Supported storage drive types The type of storage drives the device is compatible with.	HDD,SSD
Supported storage drive interfaces	M.2,Serial ATA II
Number of HDDs supported The total number of hard drives that can be used in/with this product.	6
SAS controller

Graphics
Maximum graphics adapter memory Graphics memory is determined by the (graphic) processor. Graphics memory is often shared with system memory so that it varies depending on the amount of system memory installed and system load.	32 MB
Graphics adapter family	ASPEED
Graphics adapter	AST2500
Number of displays supported The number of displays that can be used with this product.	1

Internal I/O
USB 2.0 connectors The end of a cable with a USB 2.0 connector. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), in addition to the "USB 1.x Full Speed" signaling rate of 12 Mbit/s. USB 2.0 connectors are usually colored black.	1
Number of SATA III connectors Serial ATA (Advanced Technology Attachment) (SATA) is a computer bus interface that connects host bus adapters to mass storage devices such as hard disk drives and optical drives. SATA III (revision 3.x) interface, formally known as SATA 6Gb/s, is a third generation SATA interface running at 6.0Gb/s. The bandwidth throughput, which is supported by the interface, is up to 600MB/s. This interface is backwards compatible with SATA 3 Gb/s interface.	6
Front panel connector
ATX Power connector (24-pin)
CPU fan connector
Number of chassis fan connectors	3
Peripheral (Molex) power connectors (4-pin) White 4-pinned connector used to connect a peripheral to the power supply.	3
TPM connector

Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.	3
VGA (D-Sub) ports quantity Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM.	1
USB connector type The type of USB connector/port that this product has.	USB Type-A

Network
Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Ethernet interface type	Gigabit Ethernet
LAN controller	Intel® I210-AT

Features
PC health monitoring	CPU,FAN,Temperature
Component for What this product is used as a part of (component for).	PC
Motherboard form factor Design of the motherboard (ATX, BTX etc).	Mini ITX
Motherboard chipset family The category of motherboard chipset e.g. Intel, AMD.	Intel
Cooling type The method used to cool the device or to cool the air around the device.	Active
Power source type What the power source is.	ATX
Number of mounting holes	4
Linux operating systems supported 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
Windows operating systems supported Windows vesions wich can be used with the device.

Expansion slots
PCI Express x16 (Gen 3.x) slots Places where PCI Express x16 (Gen 3.x) are placed inside and connected to the computer motherboard.	1
Number of M.2 (M) slots	1

Operational conditions
Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored.	-40 - 70 °C
Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated.	10 - 35 °C
Storage relative humidity (H-H)	20 - 90%

Weight & dimensions
Width The measurement or extent of something from side to side.	170 mm
Depth The distance from the front to the back of something.	170 mm

Packaging content
Cables included	SATA
Drivers included

Other features
HDD size The amount of data that the hard drive can store.	2.5/3.5"
Supported UDIMM clock speeds	2400,2666 MHz
Supported UDIMM module capacity	4GB,8GB,16GB
Maximum UDIMM memory	32 GB
Utilities included
Package weight Weight of the packaged product.	520 g
