1708MHz, 2 HDMI, 2 DP, 1 DVI-D
The GeForce GTX 1060 graphics card is loaded with innovative new gaming technologies, making it the perfect choice for the latest high-definition games. Powered by NVIDIA Pascal™—the most advanced GPU architecture ever created—the GeForce GTX 1060 delivers brilliant performance that opens the door to virtual reality and beyond.
Specifications
| Model | TURBO-GTX1060-6G |
| Graphics Engine | NVIDIA® GeForce® GTX 1060 |
| Bus Standard | PCI Express® 3.0 |
| OpenGL | OpenGL® 4.5 |
| Video Memory | 6GB GDDR5 |
| GPU boost Clock | 1708 MHz |
| GPU base Clock | 1506 MHz |
| CUDA cores | 1280 |
| Memory Clock | 8008 MHz |
| Memory Interface | 192-bit |
| DVI Output | 1x Native Dual-link DVI-D |
| HDMI Output | 2x Native HDMI 2.0 |
| HDCP compliant | YES |
| DisplayPort | 2x Native DisplayPort 1.4 |
| Software Bundled | ASUS GPU Tweak II & Driver |
| Max. Digital Resolution | 7680 x 4320 |
| Dimension | The card size is 10.5 x 4.376 x 1.5 inches 26.67 x 11.12 x 3.81 cm |
| Note | l To have the best cooling performance, ASUS TURBO GTX1060 extends the fansink to 2 slots. Please double check you Chassis and Motherboard dimension prior to purchase to make sure it fits in your system! l Note that the actual boost clock will vary depending on actual system conditions. For more information, please visit http://www.geforce.com/ |
| Processor | |
| CUDA CUDA (aka Compute Unified Device Architecture) is a parallel computing platform and programming model created by NVIDIA and implemented by the graphics processing units (GPUs) that they produce. CUDA gives program developers direct access to the virtual instruction set and memory of the parallel computational elements in CUDA GPUs. |
 |
| CUDA cores | 1280 |
| Graphics processor family The category to which the graphics processor (GPU) belongs e.g. Southern Islands family of Radeon processors (made by AMD), GeForce 600 (made by NVIDIA). | NVIDIA |
| Graphics processor Also known as a graphics processing unit (GPU), this is a specialized electronic circuit designed to rapidly manipulate and alter memory to accelerate the creation of images in a frame buffer intended for output to a display. GPUs are used in embedded systems, mobile phones, personal computers, workstations, and game consoles. Modern GPUs are very efficient at manipulating computer graphics. | GeForce GTX 1060 |
| Processor frequency The clock rate is the fundamental rate in cycles per second (measured in hertz) at which a computer performs its most basic operations such as adding two numbers. There are more factors, like internal memory size, that influence a computer's actual response time. | 1506 MHz |
| Processor boost clock speed | 1708 MHz |
| Maximum resolution The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. | 7680 x 4320 pixels |
| Memory | |
| Discrete graphics adapter memory | 6 GB |
| Graphics adapter memory type The type of memory used by the video card. Often a combination of dedicated memory (Video RAM or VRAM) and dynamic system memory is used. UMA stands for Unified Memory Architecture, and is a computer memory architecture that allows the graphics processing unit to share system memory. Other abreviations: RAM = Random Access Memory, SDRAM = synchronous dynamic RAM, DDR = double-data-rate. | GDDR5 |
| Memory bus Hardware and software that connects the main memory to the memory controller in computer systems. Originally, general-purpose buses like VMEbus and the S-100 bus were used, but to reduce latency, modern memory buses are designed to connect directly to DRAM chips, and thus are designed by chip standards bodies such as JEDEC. | 192 bit |
| Memory clock speed The frequency at which the memory (e.g. RAM) runs. | 8008 MHz |
| Ports & interfaces | |
| Interface type | PCI Express 3.0 |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 2 |
| DVI-D ports quantity This is the amount of DVI-I interfaces. Digital Visual Interface (DVI) is a video display interface developed by the Digital Display Working Group (DDWG). The digital interface is used to connect a video source to a display device, such as a computer monitor. DVI-D means DVI digital, which means it can only support digital, but not analog. | 1 |
| DisplayPorts quantity Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data. | 2 |
| Performance | |
| OpenGL version OpenGL (Open Graphics Library) is a specification defining a cross-language cross-platform API for writing applications that produce 3D computer graphics (and 2D computer graphics as well). The interface consists of over 250 different function calls which can be used to draw complex three-dimensional scenes from simple primitives. | 4.5 |
| HDCP High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections. |
|
| NVIDIA G-SYNC |
|
| Design | |
| Cooling type The method used to cool the device or to cool the air around the device. | Active |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 1 fan(s) |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Weight & dimensions | |
| Depth The distance from the front to the back of something. | 38.1 mm |
| Height The measurement of the product from head to foot or from base to top. | 111.2 mm |
| Width The measurement or extent of something from side to side. | 266.7 mm |
| SKU | 212933 |
| MPN | TURBO-GTX1060-6G |
| Brand | Asus |
| Product Condition | Brand New/Unused |
| Product Use | Gaming |
