ASUS Intel B760M Motherboard, HDMI, DisplayPort, Ethernet
B760M HDV/M.2 D4
- Supports 13th Gen & 12th Gen Intel Core Processors (LGA1700)
- 5 1 1 Power Phase
- Supports DDR4 5333MHz (OC)
- 1 PCIe 4.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key E for WiFi
- Graphics Output Options: HDMI, DisplayPort, D Sub
- Realtek ALC887/897 7.1 CH HD Audio Codec
- 4 SATA3, 1 Hyper M.2 (PCIe Gen4x4),
- 1 Ultra M.2 (PCIe Gen3x4 & SATA)
- 1 USB 3.2 Gen1 Type C (Rear),
- 5 USB 3.2 Gen1 Type A (3 Rear, 2 Front),
- 5 USB 2.0 (2 Rear, 3 Front)
- Realtek 1G LAN
- Supports ASRock Auto Driver Installer
| Name | Value |
|---|---|
| Audio | 7.1 CH HD Audio (Realtek ALC887/897 Audio Codec) |
| Chipset | Intel B760 |
| Form Factor | Micro ATX Form Factor: 9.6 in x 7.9 in, 24.4 cm x 20.1 cm |
| I/O Connectors | 1 x USB 3.2 Gen1 Type C (Rear) 5 x USB 3.2 Gen1 Type A (3 Rear, 2 Front) 5 x USB 2.0 (2 Rear, 3 Front) 2 x Antenna Mounting Points 1 x PS/2 Mouse/Keyboard Port 1 x D Sub Port 1 x HDMI Port 1 x DisplayPort 1.4 1 x RJ 45 LAN Port HD Audio Jacks: Line in / Front Speaker / Microphone |
| Integrated CPU Graphics | Intel Xe Graphics Architecture (Gen 12) |
| LAN | Gigabit LAN 10/100/1000 Mb/s Realtek 8111H |
| Memory/Type/Bus/Max. | Dual Channel DDR4 Memory Technology 2 x DDR4 DIMM Slots Supports DDR4 non ECC, un buffered memory up to 5333 (OC)* Supports ECC UDIMM memory modules (operate in non ECC mode) Max. capacity of system memory: 64GB* Supports Intel Extreme Memory Profile (XMP) 2.0 |
| PCI Slots | CPU: 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* Chipset: 2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)* 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module |
| Processor Support | Supports 13th Gen & 12th Gen Intel Core Processors (LGA1700) Supports Intel Hybrid Technology Supports Intel Turbo Boost Max 3.0 Technology Supports Intel Thermal Velocity Boost (TVB) Supports Intel Adaptive Boost Technology (ABT) |
| Raid | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| RAM Type/Bus/Max. | Dual Channel DDR4 Memory Technology 2 x DDR4 DIMM Slots Supports DDR4 non ECC, un buffered memory up to 5333 (OC)* Supports ECC UDIMM memory modules (operate in non ECC mode) Max. capacity of system memory: 64GB* Supports Intel Extreme Memory Profile (XMP) 2.0 |
| Socket | LGA1700 |
| Storage Interface | CPU: 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* Chipset: 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes* 4 x SATA3 6.0 Gb/s Connectors |
| Warranty | |
| Weight |
| SKU | 716519 |
| MPN | B760M-HDV/M.2-D4 |
| Brand | AsRock |
| Product Condition | Brand New/Unused |
| Case/MB Form Factor | Micro-ATX |
| Motherboard Chipset | Intel B760 |
| CPU Socket | LGA 1700 |
| Memory Type | DDR4 |
| Memory Form Factor | DIMM |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.asrock.com/ |
