APC Smart-UPS 15kVA/15kW Rack/Tower 230V/380V

Name: APC Smart-UPS 15kVA/15kW Rack/Tower 230V/380V
Brand: APC
SKU: 806076
Price: 25500 AUD
Availability: OutOfStock

Item No:

806076

MPN:

SRTG20KXLI

$25,500^.00

This product is currently not available!

Shipping Information

Store Availability

Product Summary Summary Specifications Specs Reviews Reviews

20 kW/20 kVA, Double conversion online, Sine wave, Built-in static bypass, Lead-acid battery, LCD display

Features
UPS topology The two main UPS topologies are Double-Conversion True Online and Standby / Eco. Many quality-based considerations are involved when choosing the the optimal UPS for the job, like how they are coping with voltage disturbances.	Double-conversion (Online)
Output power capacity The maximum power that the device can produce.	20 kVA
Output power The power that the device can produce.	20000 W
Waveform	Sine
Input operation voltage (min) The minumum voltage needed by the device during operation.	160 V
Input operation voltage (max) The maximum input voltage supported by the device.	415 V
Input frequency The frequency (Hz) which is required to power the product.	40/70 Hz
Output operation voltage (max) The maximum output voltage produced by the device.	230 V
Output frequency	50/60 Hz
Output frequency regulation	0.1 Hz
Maximum current The greatest possible amount of current, which is a quantity representing the rate of flow of electric charge.	87 A
Number of output phases	3
Efficiency	93%
Crest factor	3:1
Emergency Power Off (EPO)
Input current Total Harmonic Distortion (THD)	5%
Noise level The amplitude level of the undesired background noise, usually measured in decibels (db).	58 dB
Surge protection
Audible alarm(s) Alarms that make a sound when they are activated (set off).
Audible alarm modes	Alarm when on battery, Low battery alarm, Overload alarm
Auto-restart

Ports & interfaces
USB port The device features a socket into which a USB cable can be plugged.
Serial interface
Serial interface type	RS-232
SmartSlot

Battery
Battery technology The type of battery in the device, e.g. nickel–cadmium (NiCd).	Sealed Lead Acid (VRLA)
Battery voltage The voltage (V) of the battery.	192 V
Battery life (max)	5 year(s)
Battery recharge time Approximate time required to recharge the battery from completely empty to completely full	4 h
Cold start

Design
Form factor The shape or design of the product.	Rackmount/Tower
Product colour The colour e.g. red, blue, green, black, white.	Black
Display type Type of display (screen) e.g. LCD.	LCD
LED indicators
International Protection (IP) code The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".	IP20

Operational conditions
Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated.	0 - 40 °C
Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored.	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 2011.68 m
Non-operating altitude	0 - 15240 m

Weight & dimensions
Width The measurement or extent of something from side to side.	440 mm
Depth The distance from the front to the back of something.	700 mm
Height The measurement of the product from head to foot or from base to top.	306 mm
Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.	142.5 kg
Package width The distance from one side of the packaging to the other.	590 mm
Package depth The distance from the front to the back of the packaging.	790 mm
Package height The distance from the top to the bottom of the packaging.	535 mm

Packaging data
Cables included	RS-232

Logistics data
Harmonized System (HS) code	85078000
