Advantech USC-M10 10.1 PCAP TOUCH DISPLAY, Interactive flat panel, 25.6 cm (10.1"), LED, 1280 x 800 pixels
Advantech USC-M10 10.1 PCAP TOUCH DISPLAY. Product design: Interactive flat panel. Display diagonal: 25.6 cm (10.1"), Display technology: LED, Display resolution: 1280 x 800 pixels, Display brightness: 350 cd/m2, HD type: WXGA, Touchscreen. Product colour: Silver
| Display | |
| Panel type | TFT |
| Display diagonal Size of the display for this product, measured diagonally, usually in inches. | 25.6 cm (10.1") |
| Display technology The technology used in the display e.g. plasma, LED. | LED |
| Display resolution The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image. | 1280 x 800 pixels |
| Display brightness Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'. | 350 cd/m² |
| HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD). | WXGA |
| Touchscreen A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers. |
 |
| Touchscreen technology | Projected capacitive system |
| Native aspect ratio The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio. | 16:10 |
| Ports & interfaces | |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 1 |
| USB port The device features a socket into which a USB cable can be plugged. |
|
| USB ports quantity | 1 |
| USB connector type The type of USB connector/port that this product has. | USB Type-C |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
 |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
|
| Design | |
| Product design The creation of a plan or convention for the construction of an object or a system. | Interactive flat panel |
| Placement supported Where the product can be placed e.g. indoor/outdoor, horizontal/vertical. | Indoor |
| Product colour The colour e.g. red, blue, green, black, white. | Silver |
| VESA mounting |
|
| Panel mounting interface The product can be used wih VESA mounting interfaces. | 75 x 75 mm |
| Performance | |
| Purpose What the product is used for. | Commercial |
| Computer system | |
| Computer system |
|
| Built-in processor Whether or not a processor is built into the device. |
|
| Windows operating systems supported Windows vesions wich can be used with the device. |
|
| Linux operating systems supported 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3) |
|
| Weight & dimensions | |
| Display width | 244.4 mm |
| Display depth | 27 mm |
| Display height | 163 mm |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| SKU | 792068 |
| MPN | USC-M10P-STC00 |
| Brand | Advantech |
| Product Condition | Brand New/Unused |
| Screen Size (Inches) | 10.10 Inch |
| Refresh Rate (Hz) | 60Hz |
| Screen Resolution | 1280x800 |
| Input | HDMI, USB-C |
| Stock Availability | Available for Shipping |
| Product Use | Business |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.advantech.com/en-au/ |
